Big News from PCB Technologies!
New High-End SMT Lines Installed

We’re excited to announce a major upgrade at PCB Technologies! We’ve expanded our production capabilities with 2 new state-of-the-art SMT lines, featuring the advanced SIPLACE SX1 and SX2 platforms by ASMPT.

These new lines are now fully operational and have been added to our existing 7 SMT lines (in Total 9 ), reinforcing our commitment to high-performance, precision, and smart manufacturing.



SIPLACE SX1 / SX2 – High-End SMT Assembly Line at PCB Technologies

PCB Technologies has invested in 2 state-of-the-art SMT assembly lines featuring the SIPLACE SX1 and SX2 platforms by ASMPT – cutting-edge placement systems designed for speed, precision, and maximum production flexibility.

Key Highlights:

Modular & Scalable Architecture:
Dynamic “Capacity on Demand” via swappable gantries

Advanced Placement Heads:

• • CPP (MultiStar): Multi-mode placement head for a wide variety of components
  • TWIN Head: Designed for large and heavy components (up to 300g, 25mm height)
  • Component Range: From ultra-small 03015 up to 200×125 mm
  • Placement Precision: ±25 μm (with high-precision placement head)
  • Rotation Accuracy: ±0.05°
  • PCB Support: Board sizes from 50×50 mm to 850×560 mm, up to 1,525 mm length

High-Speed Performance:

• SX1:
  • Up to 43,000 CPH (ASM)
  • ~33,000 CPH (IPC)
• SX2:
  • Up to 86,000 CPH (ASM)
  • ~66,000 CPH (IPC)

Smart Capabilities:

• • Non-contact placement
  • LED alignment
  • Smart pin support
  • Automated defect detection

Software & Automation:

Full integration with WORKS software and SMT Analytics for:

• • Optimization
  • Traceability
  • Process control

Premium Inspection:

Equipped with KOH YOUNG 3D SPI and AOI systems, the new lines deliver industry-leading inspection accuracy to ensure the highest product quality.

At PCB Technologies, we deliver All-in-One Solutions for Miniaturization & Advanced IC Packaging as a leading PCB Manufacturer & Full Turnkey PCBA Services Provider. Our investment in the most advanced SMT technologies reflects our ongoing commitment to innovation, precision, and customer success.

We invite you to contact our team today and discover how we can support your next high-performance project.
